Szczegóły Produktu:
Place of Origin: China
Nazwa handlowa: Ronniewell
Orzecznictwo: CE,ISO,CSA
Model Number: HGK200
Zapłata:
Minimum Order Quantity: 1set
Cena: Contact for detail
Packaging Details: Mainframe naked, spare parts packed in case
Delivery Time: 30working days
Payment Terms: 30% TT in advance, 70% TT before the shipment
Supply Ability: 45set/month

Motorized Conventional Welding Rotator Steel Wheel Bogie Traveling

Opis
Obciążenie znamionowe: 200 ton Średnica naczynia: 1000 ~ 6500 mm
Prędkość liniowa: 100 ~ 1000 mm / min Prędkość podróżowania: 3000 mm / min
Kontrola prędkości: VFD Napięcie: 220/380/440 v / Custmomize
Atrakcja:

pipe turning rolls

,

tank rollers

Motorized Conventional Welding Rotator Steel Wheel Bogie Traveling





Brief introduction of conventional welding rotator:

  • Purpose: Used to hold and rotate circular job by required speed for welding, polishing or painting;
  • Structure: Center distance of roller is adjustable by reserved bolt screw; motorized bogie for the rotator traveling;




Conventional welding rotator feature:

  1. The welding rotator series include the self-aligned, the adjustable, the vehicle, the tilting and the anti-drift types.
  2. Conventional welding rotator can adjust the center distance by reserved screw holes or lead screw in order to adapt to diameter of work piece.
  3. Double-motor driven, the roller driver adopt cycloidal planetary gear reducer or worm reduction gear mode.
  4. According to the customer’s requirements, the roller has three forms: PU roller, steel wheels, steel and plastic combination wheel; it can joint control with other equipments.
  5. The roller is mainly used for the welding,polish rubber lining and assembly of cylindrical roller shell, but also can assembly and weld together with other tooling for the cone inequality diameter rotary.





Detail description of conventional welding rotator:

  • The series welding rotator is absorbing advantages of similar products at home and abroad, designed and manufactured by us according to the operation requirements of several pressure vessel factories.
  • According with mechanical standard JB/T 9187-1999, it is the device for special purpose adopted to weld metal cylinder especially pressure vessel.
  • It has advantages of advanced technology, reliable quality and simple operation.





Technical Parameters List:

Model

HGK-40

HGK-80

HGK-160

HGK-300

HGK-600

Max.Load capacity(ton)

40

80

160

300

600

Vessel dia. Range (mm)

600~4200

800~5000

1000~6000

1000~7500

1000~7500

Dia.& width

of roller (mm)



Rubber

400x180

450x2x200

500x2x260

/

/

Metal

/

/

/

750x280

900x450

Adjustable mode

Manual  bolt adjustment

Bolt adjustable

Motor power (kW)

2x1.5

2x3

2x4

2x7.5

2x11

Roller speed (m/min)

0.1~1 Variable Frequency Drive





Application:
1. Pressure vessels
2. Pipe manufacturing industries
3. Wind power fabrication
4. Chemical & fuel storage tank fabrication
5. Any heavy cylindrical job





Workshop picture:

Motorized Conventional Welding Rotator Steel Wheel Bogie Traveling 0





Name of the machine:
welding rotator, pipe welding rotator, pipe turning rolls, welding turning rolls, welding roller, tank turning rolls, pipe turning rolls, tube turning rolls, fit up rotator, self-aligned welding rotator, self-aligning welding rotator, self adjustable welding rotator, self aligned roller stand, wheel frame, roller frame for wind tower welding, automatic adjustable welding pipe rotator, conventional welding rotator, bolt adjustable welding rotator, sand blasting rotator, painting rotator, 1+1 hydraulic fit up rotator, two in one fit up station;
